Specification |
|
| Fail Safe: | Lock When energized |
| Face place material: | High Aluminum, Carrulous Line Finished |
| Operating Humidity: | 0~90%(non-condensing) |
| Operating temp: | -10~+25?(14-131F) |
| Induction Distance: | 8mm |
| Surface Temp: | <20*c |
| Solenoid: | Continuous duty |
| Holding force: | 1000kg |
| Current: | Start: 0.9A, Standby: 0.25A |
| Voltage: | DC12V |
| Lock pin: | 17mmDIA,stainless steel out throw12mm |
| Blot out plate size: | 148Lx44Wx25H(mm) |
| Lock body size: | 148Lx44Wx42H(mm) |
| Weight: | 0.64kg |
